Goods Name ：
Tantalum Surface Mount
Introduction：



Kemet Spec.pdf

GSM Portfolio 2016 Mini 2in1
Tantalum Surface Mount Catalog F3102
Seride Case Size Dimensions Cap Range Characteristics
KEMET/EIA LxWxH(mm)
T409 A 2.54x1.27x1.27 .22-6.8uF Mil-PRF-55365/4 & 11 (CWR09/19/29
4 - 50 Volts
∮20%; ∮10%; ∮5% Cap
 tolerance
100% Surge Current Test
 available
Tape and reel packaging
Termination Options Available
B 3.81x1.27x1.27 .47-22uF
C 5.08x1.27x1.27 .68-10uF
T419 D 3.81x2.54x1.27 1.0-33uF
E 5.08x2.54x1.27 1.5-68uF
F 5.59x3.43x1.78 3.3-100uF
T429 G 6.73x2.79x2.79 4.7-150uF
H 7.24x3.81x2.79 6.8-330uF
X 6.93x5.41x2.74 15-150uF
T491 A/3216-18 3.2x1.6x1.6 .10-100uF Industrial/commercial grade
2.5 - 50 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
B/3528-21 3.5x2.8x1.9 .15-150uF
C/6032-28 6.0x3.2x2.5 .47-330uF
D/7343-31 7.3x4.3x2.8 1.5-680uF
X/7343-43 7.3x4.3x4.0 6.8-1000uF
E/7260-38 7.3x6.0x3.6 470-1000uF
T491 R/2012-12 2.0x1.3x1.2 1.0-10uF Low profile
 2.5 - 50 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
S/3216-12 3.2x1.6x1.2 1.0-22uF
T/3528-12 3.5x2.8x1.2 3.3-100uF
U/6032-15 6.0x3.2x1.5 6.8-100uF
V/7343-20 7.3x4.3x2.0 1.0-330uF
T492 A/3216-18 3.2X1.6X1.6 .10-3.3uF Mil-PRF-55365/8 (CWR11)
4 - 50 Volts
∮20%; ∮10%; ∮5% Cap tolerance
Tape and reel packaging
100% Surge CurrentTestAvailable.
Termination Options Available
B/3528-21 3.5X2.8X1.9 .47-10uF
C/6032-28 6.0X3.2X2.5 1.5-22uF
D/7343-31 7.3X4.3X2.8 4.7-47uF
T493 A/3216-18 3.2X1.6X1.6 .10-33uF Commercial-Off-The-Shelf (COTS)
4 - 50 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
Low ESR, surge tested, Weibull
graded, termination options
B/3528-21 3.5X2.8X1.9 .15-100uF
C/6032-28 6.0X3.2X2.5 .47-220uF
D7343-31 7.3X4.3X2.8 1.5-330uF
X/7343-43 7.3X4.3X4.0 4.7-330uF
T494 A/3216-18 3.2X1.6X1.6 .10-100uF Low ESR/Industrial grade
3 - 50 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
B/3528-21 3.5X2.8X1.9 .15-150uF
C/6032-28 6.0X3.2X2.5 .47-330uF
D7343-31 7.3X4.3X2.8 1.5-150uF
X/7343-43 7.3X4.3X4.0 6.8-1000uF
E/7260-38 7.3X6.0X3.6 470-1000uF
T494 R/2012-12 2.0X1.3X1.2 1.0-10uF  Low profile/Low ESR T494 product
4 - 50 Volts
 ∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
S/3216-12 3.2X1.6X1.2 1.0-22uF
T/3528-12 3.5X2.8X1.2 3.3-100uF
U/6032-15 6.0X3.2X1.5 6.8-100uF
V/7343-20 7.3X4.3X2.0 1.0-330uF
T495 A/3216-18 3.6X1.6X1.6 .47-6.8uF Low ESR/surge robust series
4 - 50 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
Available DSCC Dwg. 95158
B/3528-21 3.5X2.8X1.9 .47-150uF
C/6032-28 6.0X3.2X2.5 2.2-330uF
D7343-31 7.3X4.3X2.8 6.8-470uF
X/7343-43 7.3X4.3X4.0 4.7-1000uF
E/7260-38 7.3X6.0X3.6 100-1000uF
T495 T/3528-12 3.5X2.8X1.2 10-100uF Low profile/Low ESR/Surge Robust
 6 -16 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
V/7343-20 7.3X4.3X2.0 68-220uF
T496 B/3528-21 3.5 x2.8x1.9 .15-22uF Fail-safe fused series
2.5 - 50 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
Available DSCC Dwg. 04053
C/6032-28 6.0x3.2x2.5 .47-100uF
D/7343-31 7.3x4.3x2.8 2.2-330uF
X/7343-43 7.3x4.3x4.0 10-470uF
GSM Portfolio 2016 Mini 2in1
Tantalum Surface Mount Catalog F3102
Seride Case Size Dimensions Cap Range Characteristics
KEMET/EIA LxWxH(mm)
T497 A 2.54x1.27x1.27 .33-4.7uF High Grade COTS
4 - 50 Volts
∮20%; ∮10% Cap tolerance
100% Accelerated Steady State Aging
100% Thermal Shock
Surge Current Testing Available
Tape and reel packaging
RoHS Compliant
Termination Options Available
B 3.81x1.27x1.27 .68-15.uF
C 5.08x1.27x1.27
D 3.81x2.54x1.27 1.5-33uF
E 5.08x2.54x1.27 2.2-68uF
F 5.59x3.43x1.78 4.7-68uF
G 6.73x2.79x2.79 6.8-68uF
H 7.24x3.81x2.79 15-100uF
X 6.93x5.41x2.74
T498 A/3216-18 3.2x1.6x1.6 .33-4.7uF 150C Maximum High Temperature
6 - 50 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
B/3528-21 3.5x2.8x1.9 2.2-33uF
C/6032-28 6.0x3.2x2.5 1.5-47uF
D/7343-31 7.3x4.3x2.8 10-100uF
X/7343-43 7.3x4.3x4.0 22-220uF
T499 A/3216-18 3.2x1.6x1.6 .15-4.7uF 175C Maximum High Temperature
6 - 50 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
B/3528-21 3.5x2.8x1.9 .47-33uF
C/6032-28 6.0x3.2x2.5 1.5-68uF
D/7343-31 7.3x4.3x2.8 3.3-150uF
X/7343-43 7.3x4.3x4.0 33-220uF
T510 X/7343-43 7.3x4.3x4.0 22-1000uF Low ESR (<10-80m)
4 - 25 Volts
∮20%; ∮10% Cap tolerance
Tape and reel packaging
RoHS Compliant
E/7260-38 7.3x6.0x3.6 47-1000uF
T520 A/3216-18 3.2X1.6X1.6 10-68uF KEMET organic with polymer cathode
2 - 25 Volts
∮20% Cap tolerance
Tape and reel packaging
RoHS Compliant
Low ESR (6 to 80m)
B/3528-21 3.5X2.8X1.9 33-330uF
C/6032-28 6.0X3.2X2.5 68-330uF
D/7343-31 7.3X4.3X2.8 15-1000uF
Y/7343-40 7.3x4.3x4.0max 330-1000uF
X/7343-43 7.3X4.3X4.0 330-1000uF
T520 T/3528-12 3.5x2.8x1.2max 15-100uF Low Profile T520 Product
KEMET organic with polymer cathode
2 - 25 Volts
∮20% Cap tolerance
Tape and reel packaging
RoHS Compliant
Low ESR (6 to 90m)
U/6032-15 6.0x3.2x1.5max 33-220uF
W/7343-15 7.3x4.3x1.5max 33-330uF
V/7343-20 7.3x4.3x1.9max 15-470uF
T525 T/3528-12 3.5x2.8x1.2 33-100uF KEMET organic with polymer cathode
2.5 - 16 Volts
∮20% Cap tolerance
125C Maximum operating temperature
RoHS Compliant
Available DSCC Dwg. 04051
B/3528-21 3.5x2.8x1.9 33-150uF
D/7343-31 7.3x4.3x2.8 47-680uF
T528 I/3216-10 3.2x1.6x1.0 33.0-100.0uF Face Down Termination Organic
Low Profile
Low ESL <0.7nH @ 20MHz
2.5 - 10 Volts
∮20% Cap tolerance
RoHS Compliant
M/3528-15 3.5x2.8x1.5 100-200uF
Z/7343-17 7.3x4.3x1.7max 150-330uF
T530 D/7343-31 7.3x4.3x2.8 150-680uF KEMET organic with polymer cathode
2.5 - 10 Volts
Ultra-low ESR (?4m available)
∮20% Cap tolerance
RoHS Compliant
Available DSCC Dwg. 04052
Y/7343-40 7.3x4.3x1.9 220-1000uF
X/7343-43 7.3x4.3x4.0 150-1500uF
